REAR PANEL
(1)TUNER ANT
Connect for AM and FM antenna
(2) AUDIO INPUT JACKS
Connect the audio output jacks of DVD/CD to these jacks
(3) RECLINE OUTPUT JACKS
Connect the RECORD input jacks to these jacks.
(4) PRE OUTPUT JACKS
Connect the professional input jacks to these jacks
(5) SUBWOOFER OUTPUT JACKS 1&2
(6) A B (Right) SPEAKER OUTPUT TERMINALS
Connect your speaker system to these terminals.
(7) A B (Left) SPEAKER OUTPUT TERMINALS
Connect your the other speaker system(s) to these terminals.
(8) COOLING FAN
(9) 110V/220V SWITCH
According to power voltage push this button to switch between 110V and 220V
(10) POWER CORD
Connect to AC 110V/60Hz & 220V/50Hz outlet.
(11)BLUETOOTH ANTENNA
This is the 2.4G bluetooth antenna
TECHNICAL SPECS:
MAX Power Output: 2000 Watt
600 Watt @ 2 Ohm
460 Watt @ 4 Ohm
240 Watt @ 8 Ohm
Frequency Response: 40Hz-15kHz, +/-2dB
Impedance: 8 Ohm
S/N Ratio: >76dB
T.H.D.: <1%
Radio Station Memory Presets: The unit can save maximum 30 stations if more than 30
stations are available.
Tuner: Quartz Synthesized Radio
Maximum USB/SD Flash Support Size: 32GB
Power: 110/220V, Switchable
Dimensions (L x W x H): 19" (w)x13.2" (d)x3.5" (h)
Unit Weight: 15.6 lbs
