PAD10MXU
2 Channel Mini Mixer With USB Audio Interface
Features:
Combo Input Connector Female/XLR And ¼ '' Phone Jack For MIC/Line
Inputs.
Line 3/2 Stereo Line Inputs RCA Plugs,To Connect Cd, Mp3 Tape Deck,
Players.
Main Out RCA Plugs To Connect The Mixer, Receiver Or Amplier.
Signal Output Thru The Headphones
Line/INSTR SW Input Select Switch Set
Line 2/3 Level This Control Adjusts The Volume Of Signal Input Of Line 2/3.
Peak Led It Lights Up Went The Input Signal Of Ch1 Is Too High.
Ch 1 Gain This Control Adjust The Volume Of Signal Input Of Ch1.
Phantom Power: 18V
Phantom Power Supply On The XLR Connector Of Ch1.
Phantom Led Indicates That Phantom Power Is On.
USB Audio Interface
Master Lets You Control Mixers Overall Volume Level
Clip Led Lights Up Went The Main Output Signal Is Too High
Monitor To Control Volume Output Of The Monitor Jack.
Power Led Indicates That The Unit Is In On Position.
Dimensions: 4.7'' x 3.8'' x 1.3'' -inches
Sold as: Unit
www.PyleUSA.com
5
