Pyle PAD12MXUBT User Manual

www.PyleUSA.com 5
11. [MAIN] Controller, used to adjust the volume of MAIN and USB PORT output.
12. [CLIP] LED, it will light up when the MAIN output signal is too high.
13. [POWER ON] LED, it will light up when the mixer’s power is on.
14. [PHONES] 3.5mm output jack, connect with earphones, it is supporting stereo
phone plug.
15. [PHONES] 6.35mm output jack, connect with earphones, it is supporting
stereo phone plug.
16. [PHONES] Controller, control the volume of earphones.
17. [AUX IN] 3.5mm jack, this is an auxiliary STEREO input, exible connectivity for
a variety of external audio devices.
18. [STEREO IN] 3.5mm jack, this is an auxiliary stereo input, exible connectivity
for a variety of external audio devices. The volume can be controlled by
external audio devices or MAIN controller.
19. [BT/USB] Convert switch, when the switch is bounce up, it connect with
Wireless BT. Press it down to connect with USB.
20. [LINE IN] Stereo RCA input jacks, connect an audio source with line signal
level, such as CD player, tape deck etc.
21. [CH 2/3 STEREO INPUT] Jacks, for connecting to line level device (e.g. electric
keyboard) via 6.35mm plugs, if only connect to L (MONO) jack, the mixer will
send out the same mono signal to L and R outputs.
22. [MAIN MIX] Stereo RCA output jacks, connect the input of an amplier or a
recorder.
23. [MAIN] Stereo 6.35mm output jacks, connect the input of an amplier or a
recorder.

Pyle PAD12MXUBT Specifications

General

Brand	Pyle
Model	PAD12MXUBT
Category	Music Mixer
Language	English
