FOREWORD
FEATURES AND CONTORLS
FRONT PANEL
1.
4.
-
-
Blue LED Output Level Indicators
2.Blue LED Display Window for MP3/Bluetooth Function.
3.Buttons for Bluetooth/MP3(USB and SD) Function Control.
-MODE Button: For audio selection like BLUETOOTH/USB/
SD/LINE IN
-PLAY/PAUSE Button: For play and pause control
-Prev,/Next: For quick backward or next song
Main Power on Switch
The amplifier is switched ON or OFF by using this switch.
5.Line input.AUX/CD IN
-Lets you easily connect the computerized MP3 Device
(player) sources, such as PC(CD ROM),laptop, walkman,
iPod, and cell phone.
6.1/4" PHONE JACK
Accepts headphones with 1/4" plug
7./8.BASS AND TREBLE TONE CONTROL
-Lets you boost or attenuate bass and treble for the desired
sound.
9.Master Volume Control
-Lets you adjust the overall sound level,turn the knob
clockwise to increase the volume.
4 5 6 7 8 9 10 11
2 31
PCAU48BT
