Pyle PFA600BU User Manual

www.PyleUSA.com
7
PFA600BU
Wireless BT Streaming Public Address Amplier
Compact PA Speaker & Microphone Receiver System with (2) Mic Inputs,
MP3/USB/SD Readers, FM Radio (300 Watt)
Features:
•
PA Public Address Amplier Receiver
• Compact Desktop Audio Source System
• Provides Convenient Microphone & Speaker Control
• Built-in Bluetooth for Wireless Audio Streaming
• Integrated Button-Activated Siren Alarm Function
• FM Radio with Digital LCD Display
• Connect & Stream Audio from External Devices
• MP3 Digital Audio File Playback Compatible
• USB Flash & SD Memory Card Readers
• USB Port Doubles as Device Charge Port
• Quick Connect Speaker Terminals
• Aux (3.5mm) Input
• (2) 1/4’’ -inch Mic Input Jacks (Mic1, Mic2)
• Front Panel Button Control Center
• LED Audio Output Indicator Lights
• Independent Audio Channel Rotary Volume Adjustment
• Optional 12V DC Power Input Terminals
Bluetooth Connectivity:
•
Built-in Bluetooth Audio Receiver
• Simple Pairing for Wireless Music Streaming
• Works with All of Today’s Latest Bluetooth Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
Technical Specs:
•
Power Output: 300 Watt MAX
• Frequency Response: +/-3dB, 100Hz-20kHz
• Impedance: 4/8/16 Ohm
• T.H.D.: <1.0%
• S/N Ratio: >70dB, Mic <80dB, Line>80dB
• Mic Input Sensitivity: 8mV
• Maximum USB/SD Memory Support: Up to 32GB
• Digital Filetype Playback Support: MP3/WAV/WMA
• Remote Control Battery: (1) x CR-2025 (included)
• Speaker Output: 4-16Ω
• Power Switch Selectable: AC/O/DC
• Power Supply: 110V, 60Hz (12V DC Input)
• Dimensions (L x W x H): 9.84’’ x 8.26’’ x 2.76’’ -inches
What’s in the Box:
•
PA Amplier
• Remote Control
• FM Antenna
• Bluetooth Version: 4.0
• Bluetooth Network Name: ‘PYLEUSA’
• Wireless Range: Up to 30’+ ft.

Pyle PFA600BU Specifications

General

Brand	Pyle
Model	PFA600BU
Category	Amplifier
Language	English
