Installation
Installthemixeronanevensurfacetoallowforsufficientairflowandventilationduringuse.Thedeviceisequippedwith
electronicallycontrolledcoolingfanstoprotectagainstthermaloverloadandinternalcircuitryfromdamagedueto
extremeheat.Pleaseavoidcoveringanysidesoftheunitorplacingobjectsorotheraudiodevicestooclosetoyourmixer.
Priortoconnectingandpoweringontheunit,makesurethatthedevicematchesthevoltageandfrequencyofyour
powersupply.Poweroffthemixerwhennotinuse.

CablesandConnections













RCA 1/4''TRSandMono XLR3Pin
RCA connector jacks have been most
commonly used in home audio systems
and configurations for years. Also known
as RCA 'phono', 'plugs' or 'audio
connectors' , these jacks  are always
unbalanced, and generally carry a line
level signal at –10 dB, nominal signal
levels. The RCA connector jacks are most
likely
 used when connecting an audio
devicelikeamediaplayerorotherhome
audio type source to your mixer.  These
connector jacks are also used when
connectingtotheoutputofyourdevices.

1/4''monoandstereoconnectorjacksare
labeled for use as unbalanced mono,
unbalanced stereo, balanced mono,
 or as
an insert patch point. A 1/4'' TRS (Tip,
Ring, Sleeve), 3conductor connection, or
'Stereo' cable allows a single connection
signal to carry 2channels of audio; also
can be used for mono balanced signals.
While,a1/4''TS(Tip,Sleeve),2conductor,
or'Mono'cablearemost
popularlyknown
for their use in guitar or linelevel
instrument connection; they can also be
usedformonounbalancedsignals.

XLRconnectorjacks,almostalwayscarries
a balanced signal. Depending on your
device,theseconnectorjacksmayalsobe
capable of handling unbalanced signals.
Microphones generally have this type
of
connector, as well as most other
professionalaudioequipmentanddevices.
Typical3PinXLRsocketsarefixedwiththe
rightmostpinbeingthe'ground',theleft
most pin being 'hot'  and the bottom pin
asthe'neutral'.


  TechnicalSpecifications
MonoInputs
MicrophoneInputs(XENYXMicPreamp)
XLR,electronicallybalanced,discreteinputcircuit
MicE.I.N.(20Hz20kHz)
@0OhmSourceResistance
@50OhmSourceResistance
@150OhmSourceResistance
134dB/135.7dBAWeighted
131dB/133.3dBAWeighted
129dB/130.7dBAWeighted
FrequencyResponse
<10Hz150kHz(1dB)
<10Hz200kHz(3dB)
GainRange +10dBto+60dB
MaximumInputLevel +12dB@+10dBGain
Impedance Approximately2.6kOhm,Balanced
SignaltoNoise 110dB/112dBAWeighted
Distortion(THD+N) 0.005%/0.004%,AWeighted
LineInput 1/4''TRSConnectors,ElectronicallyBalanced
ChannelEqualization
(FrequencyHz)
ControlRangeHigh:@10k+/15dB
ControlRangeLow:@60k+/15dB
Master5BandGraphicEQ
Frequency:Hz(60,250,1K,4K,12K)
ControlRanges:+/12dB
