Pyle'PMX'SeriesMultiChannelMixers
www.PyleAudio.com
ConnectorSpecifications
EffectsConnectors
EffectsSendEffectsReturn
1/4''TSConnector,Unbalanced
Impedance:Approx.1kOhm
OutputLevel:10dB
ControlRoomOutputs
RCAUnbalanced
Impedance:Approx.1kOhm
OutputLevel:10dB
HeadphoneOutput
1/4''TRSConnector,Stereo
OutputLevel:+19dB/150Ohm(+25dB)
MixerLayoutandControlsFrontPanel
1.
3PINLOWIMPEDANCEMICINPUT
Electronically balanced XLR input is designed to accept signals from any
balancedor unbalanced low impedance (Low Z)microphone. (Pin 1 to the
shield,Pin2tothe'hot'(positivepolarity)sideoftheaudiosignal,andPin3
tothe'cold'sideofthesignal.Dynamicorribbontypemicrophones
donot
require phantom power. Microphone inputs are generally more sensitive
thantheLineinputs.
2.
1/4''LINEINPUT
Line/High impedance input, 1/4” connector jack is designed to accept
balanced or unbalanced linelevel signals such as those from keyboards,
drum machines, or samplers. There is enough gain available on the line
inputtoacceptevenlowerlevelsignals,suchasthosefromanunbalanced
microphoneorguitaroutput.Ifabalancedsignalistobeconnectedtothe
line input, then a1/4” TRS (stereo) phone plug shouldbe wiredfor: Tip =
positive(+),Ring=negative(),Sleeve=ground.
*Pleasenote, the diagram above doesnot reflect all Pyle'PMX' Series models. Somefeatures listed are model specific,and are just madefor descriptive
purposesforamorethoroughunderstandingofthePMXSeriesMixers.Toviewmodelspecificinformation,pleasevisitwww.PyleAudio.comandbrowsefor
thespecificmodelnumber.(PMXMixerSeriesModels:PMX401,PMX402M,PMX602M,PMX630I,PMX640BT,PMX802M,PMX830I,PMX840BT)
