Pylontech P-Combiner-HV-3 User Manual

Basic Parameters
P-Combiner-HV-3
P-Combiner-HV-6
Maximum output current
50A
100A
Ict current of fuse
10kA/100ms
15kA/100ms
Fuse protection breaking capacity
50kA@750V DC
Disconnecting switch capacity
12kA@1500V DC
Weight
11.5kg
11.7kg
Dimension
400*385*200
Working temperature range
-20℃~55℃
IP rating/type of enclosure
IP55/NEMA 3S
Humidity
5% ~ 95%(RH) No Condensation
Altitude(m)
≤4000
Design life
15+ Years (25℃/77℉)
Reference standard
IEC61439-1, IEC61439-2, UL1741
2.1 Equipment interface instruction
1）Power Terminal Input
Connect to Force-H-V2 battery power terminals.
*Make sure the battery type selected do support parallel operation features.
