Pyramid PB1644X - Pyramid Amplifier Speaker Connections; PB844 4-Channel Speaker Connections; Pyramid Amplifier Features and Controls; PB844 4-Channel Features and Controls

5
18
4ch amp PB844
speakers
R
MINIMUN
SPEAKER
IMPEDANCE
4OHMS!
L
PB844
speaker connections
features and controls
4ch amp PB844
CH3/4 high pass frequency control
CH3/4 crossover mode selector control
CH1/2 input level control
CH3/4 level inputs
CH1/2 level inputs
output level
CH 1/2speaker connections
power terminals
power fuse
power LED
protection LED
CH3/4 speaker connections
2/3/4 channel selectorl switch
CH1/2 high pass frequency control
CH3/4 low pass frequency control
CH3/4 bass boost level control
CH3/4 input level control
remote bass boost
CH1/2 crossover mode selector switch
CH1/2 bass boost level control
CH1/2 low pass frequency control
PB844
2CH Bridged Output Mode with Subwoofer Output
SUBWOOFER
