END
Microwave at 10M
Do not partially or
completely obscure
the detector’s eld of view
with large objects
Lens 5. 90˚,
78 Zones, 5 Planes.
<10kg
XD-WALLBRACKETXD-WALLBRACKET + XD-45D-ADAPTER
Max: 15m
0m
Approx 10m
XD-FIXEDBRACKETXD-FIXEDBRACKET
BOTTOM PIR
TOP PIR ALARM MICROWAVE
Top PIR Failed Self Test
Microwave Failed Self Test
Powering Up
Masked/Blocked
Bottom PIR Failed Self Test
Low Voltage
Top PIR Activated
Microwave Activated
Bottom PIR Activated
Alarm
Mask Processing
0845 6434 999 (UK). +44(0)1709 535 225 customer.support@pyronix.com www.pyronix.com Pyronix Limited, Pyronix House, Braithwell Way, Hellaby, Rotherham, S66 8QY, UK
