9
• NEVER use cleaning solvents with flash
points below 140 degrees F. Some of
these are: acetone, benzene, ether,
gasoline, naptha. Consult your supplier
to be sure.
ASSEMBLY
Tools needed: Two adjustable wrenches-not
included.
1. Attach the hose to the pump and
tighten with a wrench.
2. Attach the hose to the gun and tighten
with two wrenches.
ELECTRICAL CONNECTION
The network voltage must conform to the
voltage indicated on the tool name
plate. Under no circumstances should
the tool be used when the power supply
cable is damaged. A damaged cable
must be replaced immediately by an
authorized Customer Service Center.
Do not try to repair the damaged cable
yourself. The use of damaged power
cables can lead to an electric shock.
FLUSHING SAFETY
WHEN SPRAYING & CLEANING WITH
FLAMMABLE PAINTS AND THINNERS
1. When spraying with flammable liquids,
the unit must be located a minimum of
25 feet away from the spraying area in
a well ventilated area. Ventilation must
be sufficient enough to prevent the
accumulation of vapors.
2. To eliminate electrostatic discharge,
ground the spray unit, paint bucket
& spraying object. See GROUNDING.
Use only high pressure airless hoses
approved for 3000 psi which is
conductive.
3. Remove the spray tip before flushing.
Hold the metal part of the gun rmly to
the side of a metal pail & use the lowest
possible uid pressure during ushing.
4. Never use high pressure in the cleaning
process. USE MINIMUM PRESSURE.
5. Do not smoke in spraying/cleaning
area.
Symbols used in this manual
V……........volts
A……........amperes
Hz…….......hertz
W……........watt
~……….....alternating curren
............read these instructions
............do not dispose of electric tools,
accessories and packaging
together with household waste
material
