QED AP4 Ultra User Manual

Figure 7 - Hose Bundling
Tie-Wrap Detail
Figure 8 Tie-Wrap Layout
Thread Tie-Wraps
Through Support Line
Air Exhaust Tie-Wrap
AutoPump Air
Hose (Green)
Fluid Discharge
Hose (Black)
Air Exhaust
Hose (Blue)
Air Exhaust
Tie-Wrap
Support Rope
AutoPump® Air
Hose (Green)
Fluid Discharge
Hose (Black)
Air Exhaust
Hose (Blue)
Quick Link Assembly
Support Rope
Support Harness
Air Hose Tie-Wrap
AutoPump Air
Hose (Green)
Fluid Discharge
Hose (Black)
Air Exhaust
Hose (Blue)
Air Hose
Tie-Wrap
Support Rope
Air Exhaust Tie-Wraps in Between Air Hose Tie-Wraps Every 4 Ft. (122 Cm)
Air Exhaust Tie-Wraps in Between Air Exhaust Tie-Wraps Every 4 Ft. (122 Cm)
Revision 3 - December, 2013Revision 3 - December, 2013
13
