12
Screw hole
cover
Screw hole
cover
Screw hole
Screw
4.4. REVERSE THE DOOR SWING
Tools required:
Cross-head
screwdriver
Putty knife &
thin-blade screwdriver
5/16” socket and
ratchet
Masking tape
Note: The above tools are not supplied.
1. Power off the refrigerator, and remove all objects from the door trays.
2. Dismantle the screw hole caps, screws and handle, and remove the plastic screw hole
caps from the other side. Please refer to section INSTALL THE DOOR HANDLE.
3. Dismantle the upper hinge cover, screws and upper hinge, and remove the
hole cover from the other side. Unplug the wiring connector on the right side of
refrigerator top ( ,
wiring connector).
To Next Page
