Qilive Q.6621 - Page 13

13
EN
Hole cover Hinge cover
4. Dismantle the door and right bottom hinge assembly (hinge shaft, adjustable foot,
hinge, and hinge screws), and assemble the hinge shaft and adjustable foot on
the other side of hinge, then assemble the whole hinge assembly on the other
side of refrigerator.
Hole cover
Hole cover
5. Remove the door end cover, install the upper hinge sleeve and door signal line to
the other side and install the door end cover.
Dismantle the door stopper and sleeve pipe from the right bottom of door, insert
the sleeve pipe into hinge hole in left bottom of door, then assemble door stopper
on left bottom of door.
Door signal line
Door end cover
Sleeve pipe
Sleeve pipe
Stopper
Stopper screw
