8
EN
2. TECHNICAL DATA
Rated voltage/power input 220 - 240 V/AC, 50 W
Maximum air output (F) 50.25 m³/min
Service value (SV) 1.11 (m³/min)/W
Standby energy consumption (P
SB
) 0.352 W
Fan sound power level (LWA)
58.14 dB(A) (high speed); 46.16 dB(A)
(low speed)
Maximum air speed (c) 4.12 metres/sec
Service value measurement standard IEC 60879:1986
Dimension 400 x 360 x 1135 mm
Weight 5.33 kg
Delivery content
1 x stand fan; 1 x remote control with a
CR2025 battery; 1 x user manual
3. DESCRIPTION
3.1 Main unit
1. Front guard
2. Blade assembly nut
3. Blade assembly
4. Rear guard nut
5. Rear guard
6. Engine shaft
7. Carry handle
8. Engine unit
9. Mains cable with plug
10. Upper stand tube
11. Lower stand tube
12. Base
13. Control panel
14. Safety screw
3.2 Remote control
15. Power button
16. Speed down button
17. Oscillation button
18. Timer button
19. Speed up button
4. INSTALLATION
After unpacking, check for completeness of delivery and for shipping damage. If your
delivery is damaged or incomplete, please contact our after-sales service.
1.
• Insert the upper stand tube (10) to the bottom of the engine unit and tighten the
upper stand tube (10) by turning it anticlockwise.
