Qlightec ST45 User Manual

4 5
• Signal/ Audible line current(Per each layer)
Model number
Layer
count
Voltage Current Certicate Weight Color
* ST80ML
* ST80ML-BZ
ST80ML-WS
ST80ML-WM
ST80ML-WA
ST80MLF
ST80MLF-BZ
ST80MLF-WS
ST80MLF-WM
ST80MLF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.160A
0.080A
0.055A
0.027A
0.40kg
0.40kg
0.64kg
0.64kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.320A
0.160A
0.064A
0.032A
0.54kg
0.54kg
0.78kg
0.78kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.480A
0.240A
0.073A
0.036A
0.68kg
0.68kg
0.92kg
0.92kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.640A
0.320A
0.084A
0.042A
0.83kg
0.83kg
1.06kg
1.06kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.800A
0.400A
0.093A
0.046A
0.97kg
0.97kg
1.20kg
1.20kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Current Certicate Weight Color
* ST80MEL
* ST80MEL-BZ
ST80MEL-WS
ST80MEL-WM
ST80MEL-WA
ST80MELF
ST80MELF-BZ
ST80MELF-WS
ST80MELF-WM
ST80MELF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.080A
0.040A
0.046A
0.023A
0.36kg
0.36kg
0.59kg
0.59kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.160A
0.080A
0.051A
0.025A
0.45kg
0.45kg
0.68kg
0.68kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.240A
0.120A
0.057A
0.028A
0.55kg
0.55kg
0.76kg
0.76kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.320A
0.160A
0.064A
0.032A
0.64kg
0.64kg
0.87kg
0.87kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.400A
0.200A
0.071A
0.035A
0.73kg
0.73kg
0.96kg
0.96kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Current Certicate Weight Color
* ST80L
* ST80L-BZ
ST80L-WS
ST80L-WM
ST80L-WA
ST80LF
ST80LF-BZ
ST80LF-WS
ST80LF-WM
ST80LF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.160A
0.080A
0.055A
0.027A
0.62kg
0.62kg
0.86kg
0.86kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.320A
0.160A
0.064A
0.032A
0.77kg
0.77kg
1.00kg
1.00kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.480A
0.240A
0.073A
0.036A
0.91kg
0.91kg
1.14kg
1.14kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.640A
0.320A
0.084A
0.042A
1.05kg
1.05kg
1.29kg
1.29kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.800A
0.400A
0.093A
0.046A
1.19kg
1.19kg
1.14kg
1.14kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Current Certicate Weight Color
* ST80EL
* ST80EL-BZ
ST80EL-WS
ST80EL-WM
ST80EL-WA
ST80ELF
ST80ELF-BZ
ST80ELF-WS
ST80ELF-WM
ST80ELF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.080A
0.040A
0.046A
0.023A
0.58kg
0.58kg
0.81kg
0.81kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.160A
0.080A
0.051A
0.025A
0.67kg
0.67kg
0.91kg
0.91kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.240A
0.120A
0.057A
0.028A
0.77kg
0.77kg
1.00kg
1.00kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.320A
0.160A
0.064A
0.032A
0.86kg
0.86kg
1.09kg
1.09kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.400A
0.200A
0.071A
0.035A
0.95kg
0.95kg
1.19kg
1.19kg
R-Red
A-Amber
G-Green
B-Blue
W-White
•
ST80ML
•
ST80MEL
•
ST80L
•
ST80EL
Model number Current AC/DC12V AC/DC24V AC110V AC220V
ST45ML
ST45L
Signal line current 0.040A 0.040A 0.024A 0.012A
Audible line current 0.016A 0.031A 0.027A 0.030A
ST56MEL
ST56EL
Signal line current 0.060A 0.040A 0.044A 0.022A
Audible line current 0.016A 0.031A 0.027A 0.030A
ST56ML
ST56L
Signal line current 0.120A 0.080A 0.048A 0.024A
Audible line current 0.016A 0.031A 0.027A 0.030A
ST80MEL
ST80EL
Signal line current 0.080A 0.040A 0.046A 0.023A
Audible line current 0.016A 0.031A 0.027A 0.030A
ST80ML
ST80L
Signal line current 0.160A 0.080A 0.055A 0.027A
Audible line current 0.016A 0.031A 0.027A 0.030A
Product Specications
※
Models with an asterisk mark (*) have certication.
※
CE compliant : DC24V, DC12V/24V(ST80EL, ST80EL)
※
UL listed : DC24V
