4
46
6.
Insert the indoor fixing ring from the vent cover onto the indoor side of the air
vent. Then fold the external vent cover in half. Attach the chains to each side
of the vent cover, before sliding the cover outside through the vent hole. 6
7. Expand the external cover, before tightly fixing the chains by hooking onto
the indoor fixing ring. This will hold the external cover firmly in position.
Repeat for the second vent.
7
8. Once the chains are fitted and secure, any excess chain should be removed by
cutting the chain.
8
9. Lift the unit onto the wall, align the hanging holes with the hooks on the
hanging rail and gently rest the unit into place. At the same time, slide the
drain pipe through the drainage hole. If the wireless controller (Available
separately) has been purchased, it should then be installed, and connected.
9
NOTE: The end of the external water pipe must be placed in an open space or
drain. Avoid damage or constriction to the drainage pipe to ensure the unit
drains.
