QNAP QHora-321 Quick Installation Guide

QHora-321 Rear Panel LEDs
LED Status Description
5
2.5 Gigabit
Ethernet LED (2.5
Gbps speed)
Green The network connection is operating at 2.5 Gbps.
Flashes green Data is being transmitted.
Off There is no network connection.
6
2.5 Gigabit
Ethernet LED (1
Gbps or 100 Mbps
speed)
Orange
The network connection is operating at 1 Gbps or
100 Mbps.
Flashes orange Data is being transmitted.
Off There is no network connection.
Wide Area Network (WAN) and Local Area Network (LAN) LEDs
7
QHora-321 assigns the default WAN interface role to
port number 1. The following LED status indicates the
network port role:
WAN interface - Orange
LAN interface - Green
QHora Series
QHora Series
1 WAN 2 3 4 5 6
DC IN
Reset
GREEN=LAN
AMBER=WAN
7
5 6

QNAP QHora-321 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Concurrent connections	50000
Ethernet LAN data rates	100, 1000, 2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet
Flash memory	4 MB
Certification	CE / FCC / VCCI / BSMI / RCM / CCC / UKCA
Storage media	Flash
Internal memory	4096 MB
Processor model	CN9130
Processor frequency	2.2 MHz
Internal memory type	DDR4
Processor manufacturer	Marvell
Internal storage capacity	4 GB
Web-based management	-
Output voltage	12 V
Power source type	DC
Power consumption (typical)	36 W
Package weight	1350 g
Cables included	AC, LAN (RJ-45)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Ethernet LAN (RJ-45) ports	6
Product color	White
VPN support	L2TP, WireGuard, OpenVPN, QBelt
Firewall security	TCP, UDP, ICMP, TCP+UDP

Weight and Dimensions

Depth	145.7 mm
Width	166.4 mm
Height	29.85 mm
Weight	810 g
