14
TD-001571-01-B
SPECIFICATIONS
CP8 CP12
Configuration: Two-way active loudspeaker Two-way active loudspeaker
LF Transducer: 8 inch (203 mm) cone 12 inch (305 mm), cone
HF Transducer: 1.4 inch (35.6 mm) compression driver 1.4 inch (35.6 mm) compression driver
Frequency Response (-6 dB): 56 - 20 kHz 49 - 20 kHz
Frequency Range (-10 dB): 53 - 20 kHz 47 - 20 kHz
Nominal Coverage Angle: 90° Axisymetric 75° Axisymetric
Maximum Rated SPL
1
: 124 dB 126 dB
Amplifier: Class D
Peak: 800 W (LF), 200 W (HF)
Controls: Power
2 x Gain
MIC BOOST Push Switch
6-way Contour Selection Switch
Indicators: Power LED
2 x Input Signal LED
Input B MIC BOOST selected LED
Limiter active LED
Connectors: 2 x locking XLR/F ¼ inch combo (LINE Input and MIC/LINE input)
1 x 3.5 mm TRS (Stereo Input)
1 x XLR/M (Mix Output)
1 x IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power: 100 VAC, 0.75A -240VAC 0.31A
Enclosure Material: Polypropylene
Attachment Points: 2 x M8 threaded insert (for yoke mount attachment only)
Color: Black
Grille: 18 Gauge powder coated steel
Dimensions (HxWxD): 16.2 x 10.7 x 10.1 inch
411 x 273 x 256 mm
20.3 x 13.8 x 12.7 inch
516 x 350 x 323 mm
Net Weight: 21.0 lb (9.5 kg) 30.3 lb (13.7 kg)
Shipping Weight: 25.5 lb (11.4 kg) 36.3 (16.5 kg)
Regulatory: UL, CE, CCC, FCC Class B
Optional Accessories: CP8 Tote, CP8 Outdoor Cover CP8 Yoke CP12 Tote, CP12 Outdoor Cover CP12 Yoke
1 Peak SPL is measured on-axis at 1 m, with dynamic pink noise
NOTE: Specifications subject to change without notice.
