Qsonica Sonicator User Manual

Rev. 3-11
6
3. Specifications
Generator
Input Voltage 100 VAC – 120 VAC @ 50/60 Hz
220 VAC – 240 VAC @ 50/60 Hz
Rated Current
2.4 Amps max. 1.2 Amps max.
Fuse Rating
3 Amps (slo-blo)* 1.6 Amps (slo-blo)*
Weight
7 lbs. (3.2
Kg)
Dimensions 8"W x13.75"L x 5.75"H
203mm x 349mm x 146mm
Output Voltage 1000 V rms (max.)
Output Frequency 20 KHz
Converter
Weight 0.75 lbs. (0.34Kg)
Dimensions 6" L x 1.25" Dia.
(15cm x 3cm)
Materials Aluminum Alloy
Standard 1/8”
Microtip
Weight 0.25 lbs. (0.11Kg)
Dimensions 5.4" L x 0.5" Dia.
(13.8cm x 1.3cm)
Materials Titanium Alloy

Qsonica Sonicator Specifications

General

Frequency	20 kHz
Amplitude Range	20-100%
Pulse Mode	Yes
Display	Digital
Probe Diameter Options	1/2", 3/4"
Voltage	110V or 220V
