QT Technologies
M3000
SITE PREPARATION CHECKLIST
The terms of this site installation (as agreed) are for an authorized factory technician to
be on site for start-up and training. The following items must be fully completed prior to
our technician booking travel to site. Additional charges may be incurred if site prepa-
ration is not completed as stated. Please initial each item, and sign form and fax to QT
Technologies @ (303) 444-8736. An installation cannot be scheduled until this sheet is
received, fully completed.
Terminal / Dispenser System Related Requirements
1. A low voltage conduit (or shielded cable in conduit B) going from each dispenser Junction Box to the
terminal pedestal with at least five #16 AWG (See Figure 5 or 6 — Dispenser Field Wiring Diagram,
conduit A). If LEVEL 2 grounding is desired, a conduit going from the low voltage J-Box to the
ground reel with two # 16 AWG wires is needed. The wire size may have to be increased on long
distances or runs.
Completed on ___/___/___ by _____________
2. A high voltage conduit going from each dispenser J-Box to the terminal pedestal with at least six #14
AWG wires (See Figure 5 or 6 — Dispenser Field Wiring Diagram, conduit B). Other wires such as
220v pump, hose reels, etc., would need extra wires for their support needs. The wire size may
need to be increased on long distances or runs.
Completed on ___/___/___ by _____________
3. A low voltage conduit going from the terminal pedestal to the phone company connection with live
dedicated* phone line. This conduit has at least 2 pair (4 wires) phone line. (See Figure 5 or 6 —
Dispenser Field Wiring Diagram, conduit C)
*Note: This phone line must be dedicated - It CANNOT share the line/telephone number with other de-
vices such as fax machines, telephones, computer modems, etc. It can share the phone line with other
credit card machines provided they do not answer the phone for any reason.
Terminal Phone #( ) _______ - ______________
Completed on ___/___/___ by _____________
4. All wiring to run the pump is completed (See Figure 5 or 6 — Dispenser Field Wiring Diagram, con-
duit E or F). One wire per pump control relay is required in conduit E if the relay(s) are located at or
near the Breaker Panel.
Completed on ___/___/___ by _____________
