QT Technologies
M3000
SITE PREPARATION CHECKLIST FOR
SERIAL PROTOCOL DISPENSERS
The terms of this site installation (as agreed) are for an authorized factory technician to
be on site for start-up and training. The following items must be fully completed prior to
our technician booking travel to site. Additional charges may be incurred if site prepa-
ration not completed as stated. Please initial each item, and sign form and fax to QT
Technologies @ (303) 444-8736. An installation cannot be scheduled until this sheet is
received, fully completed.
Terminal / Dispenser System Related Requirements
1. A low voltage conduit going from each dispenser Junction Box to the terminal pedestal with at least
a six conductor shielded cable #20-24 AWG (See Field Wiring Diagram on the previous page). If
LEVEL 2 grounding is desired, a conduit going from the low voltage J-Box to the ground reel with
two # 16 AWG wires is needed. The wire size may have to be increased on long distances or runs.
Completed on ___/___/___ by _____________
2. A low voltage conduit going from the terminal pedestal to the phone company connection with live
dedicated* phone line. This conduit has at least 2 pair (4 wires) phone line. (See See Field Wiring
Diagram on the previous page) *Note: This phone line must be dedicated - It CAN NOT share the
line/telephone number with other devices such as fax machines, telephones, computer modems,
etc.
Terminal Phone #( ) ______-______________
Completed on ___/___/___ by _____________
3. A high voltage conduit going from the terminal pedestal to the breaker box (See See Field Wiring
Diagram on the previous page). The conduit will contain a dedicated ground, neutral, hot for the ter-
minal.
Completed on ___/___/___ by _____________
