25
Gear Head
QTech QT650 Airless Sprayer
ITEM PRODUCT CODE DESCRIPTION QTY
40 12-068 PUMP CARRIER CLAMP 1
41 12-141 SOCKET CAP SCREW (M10x50xP1.5) 4
42 12-160 SPRING WASHER (M10) 4
43 12-090 T-HANDLE BOLT 1
44 12-148 PANHEAD MACHINE SCREW-W/WASHER (M6x1 0xP1.0) 1
45 12-144 BUTTERFLY SCREW (M6x10xP1.0) 1
46 12-155 FLAT WASHER (Ø6.5xØ13x1) 2
47 12-072 FENCE 1
48 12-127 BUSHING (Ø48xØ54x43) 1
49 12-128 BUSHING (Ø48xØ54x43) 1
50 12-073 GUIDE CYLINDER PLATE 1
51 12-137 TRUSS HEAD MACHINE SCREW (M5x8xP0.8) 4
52 12-080 RETAINING RING (Ø1.5xØ44xØ47) 1
53 12-092 PUMP WRIST PIN (Ø12x52) 1
54 12-165 DRIVE PISTON 1
55 12-093 PUMP WRIST PIN (Ø20x42) 1
56 12-094 PISTON/CONNECTING ROD ASSY 1
57 12-099 NEEDLE BEARING (TA 2530) 1
58 12-650-010 SPINDLE 1
59 12-151 PARALLEL KEY (5x5x15) 2
60 12-100 NEEDLE BEARING (TA 5530) 1
61 12-054 GEARCASE 1
62 12-138 SOCKET CAP SCREW (M6x40xP1.0) 4
63 12-158 SPRING WASHER (M6) 12
64 12-059 GEAR CAP (SILVER) 1
65 12-129 CLUTCH BRASS DISC (Ø46xØ63x2) 1
66 12-650-012 OUTPUT GEAR (M2.5x54T) 1
67 12-083 CLUTCH NUT (M30xP2.0) 1
68 12-101 BALL BEARING (6203) 3
69 12-100 GEAR PLATE (SILVER) 1
70 12-107 MOUNTING BLOCK 1
71 12-158 SPRING WASHER (M6) 12
72 12-138 SOCKET CAP SCREW (M6x35xP1.0) 8
73 12-138 SOCKET CAP SCREW (M6x35xP1.0) 8
74 12-158 SPRING WASHER (M6) 12
75 12-101 BALL BEARING (6203) 3
76 12-650-16 INPUT SHAFT (M2.5x16T) 1
77 12-150 PARALLEL KEY (5x5x12) 2
78 12-102 INPUT GEAR (M1.5x59T) 1
79 12-153 EXTERNAL CIRCLIP (S-25) 1
80 12-101 BALL BEARING (6203) 3
To Next Page
