QTech QT650 User Manual

26
Motor
SprayForthedecorator.com
27
Motor
QTech QT650 Airless Sprayer
ITEM PRODUCT CODE DESCRIPTION QTY
81 12-074 TOOL BOX PLATE 1
82 12-145 PANHEAD MACHINE SCREW-W/WASHER (M5x12xP0.8) 8
83 12-105 TOOL BOX 1
84 12-154 FLAT WASHER (Ø5xØ10x1) 8
85 12-145 PANHEAD MACHINE SCREW-W/WASHER (M5x12xP0.8) 8
86 12-084 HINGE PIN (Ø3x230) 1
87 12-104 TOOL BOX LID 1
88 12-106 TOOL BOX LOCK 1
89 12-650-17 PANHEAD TAPPING SCREW-B (M5x16) 2
90 12-154 FLAT WASHER (Ø5xØ10x1) 8
91 12-108 MOTOR CAP 2
92 12-159 SPRING WASHER (M10) 8
93 12-146 PANHEAD MACHINE SCREW-W/WASHER (M5x20xP0.8) 1
94 12-145 PANHEAD MACHINE SCREW-W/WASHER (M5x12xP0.8) 8
95 12-154 FLAT WASHER (Ø5xØ10x1) 8
96 12-159 SPRING WASHER (M10) 8
97 12-149 NYLOCK NUT (M10xP1.5) 4
98 12-140 SOCKET CAP SCREW (M10x25xP1.5) 4
99 12-159 SPRING WASHER (M10) 8
100 12-650-19 MOTOR UNIT (110V&220V-2.5HP) 1
101 12-131 HEX BOLT (M10x20xP1.5) 4
