To program the Site name to Shed1, name Input 1 as Pump and set notification escalations to
phones 1, 2 and 3. You can either send the SMS Lite 3 individual configuration text messages:
e.g. #12345 Site:Name=Shed1.
#12345 INP1:Name=Pump.
#12345 INP1:Phones=Ph1,Ph3.
Or you can send 1 combined message:
e.g. #12345 Site:Name=Shed1. INP1:Name=Pump. INP1:Phones=Ph1,Ph2, Ph3.
Escalations
When programming the alarm escalations to phone numbers it is important to note that the
numbers step in numerical order.
E.g. Ph1→Ph2→Ph4 and Ph1→Ph2→Ph3 will work, however if you were to attempt to program
Ph4→Ph2→Ph3, the configuration text would be accepted but the escalation order would
be Ph2→Ph3→Ph4.
Text commands can be in upper or lower case; however, any capitalisation when naming the Site,
Input or Outputs will be retained.
e.g. #12345 Site:Name=Shed1.
is valid as
#12345 site:name=shed1.
Note: Each Input and Output must have a unique name.
Advanced Commands
Debouncing Inputs
This feature prevents the SMS Lite from sending multiple messages when connected to devices such
as float switches, which can switch on and off several times before settling due to contact bounce.
You can program a delay before the text message is sent by the SMS Lite.
The trigger point / device that is connected to the SMS Lite must stay in that state for the ‘debounce’
time that is set, before the SMS Lite will send a text message alerting you of a status change.
The delay is configurable, and you can select one of the following options: 0, 5, 10, or 30 seconds, or
1, 5, 10, or 15 minutes.
The debounce value is "global" to all inputs - you cannot specify different values for each input.
