Qtx C-BAR - DMX 14 Channel Mode; DMX 26 Channel Mode

151.592UK User Manual
DMX 14 channel mode
Channel
Value
Function
1
0-255
Section 1
Master dimmer
2
0-255
Strobe
3
0-255
Red 0-100%
4
0-255
Green 0-100%
5
0-255
Blue 0-100%
6
0-255
Auto program
7
0-255
Section 2
Master dimmer
8
0-255
Strobe
9
0-255
Red 0-100%
10
0-255
Green 0-100%
11
0-255
Blue 0-100%
12
0-255
Auto program
13
0-255
See Colour Chase Table
14
0-255
Chase speed slow to fast
DMX 26 channel mode
Channel
Value
Function
1
0-255
Section 1
Master dimmer
2
0-255
Strobe
3
0-255
Red 0-100%
4
0-255
Green 0-100%
5
0-255
Blue 0-100%
6
0-255
Auto program
7
0-255
Section 2
Master dimmer
8
0-255
Strobe
9
0-255
Red 0-100%
10
0-255
Green 0-100%
11
0-255
Blue 0-100%
12
0-255
Auto program
13
0-255
Section 3
Master dimmer
14
0-255
Strobe
15
0-255
Red 0-100%
16
0-255
Green 0-100%
17
0-255
Blue 0-100%
18
0-255
Auto program
19
0-255
Section 4
Master dimmer
20
0-255
Strobe
21
0-255
Red 0-100%
22
0-255
Green 0-100%
23
0-255
Blue 0-100%
24
0-255
Auto program
25
0-255
See Colour Chase Table
26
0-255
Chase speed slow to fast
