63
To prevent engine damage, only use spark plugs of the
recommended type.
Fig. 02
QSI0048
6.7 DRAINING EVAPORATED OIL
•
Position a suitable container directly underneath the airbox.
• Remove the circlip shown in the figure.
• Remove the cap «2» and empty out all oil which has accumulated
inside it.
• Dispose of the oil in an environmentally friendly manner and in
accordance with local regulations.
It is highly recommended that you have the-
se operations performed by an authorised
service centre or qualified personnel.
Fig. 01
QSI0047
• Remove the park plug «1 - Fig. 01» using a box spanner,
• Clean off any dirt and carbon residue from the spark plug.
Check the spark gap.
• Manually screw the spark plug in its seat.
• Serrare la candela.
• Carefully refit the spark plug cap
Recomended Spark plug: NGK CR8E
Spark gap: 0,6 ÷ 0,7 mm
(Fig. 02)
MAINTENANCE VEHICLE
