Qualcast 310099 - Chainsaw Technical Specifications

32 33
Technical Data
Engine displacement 45.4cm
3
Maximum engine capacity 1.6kW
Bar length 45cm
Cutter rail length 42cm
Chain gauge (0.050˝), 1.27mm
Idling speed 3300min
-1
Maximum speed with cutting equipment 11500min
-1
Chain speed 16.7m/s
Fuel tank capacity 270ml
Oil tank capacity 190ml
Anti-vibration function Yes
Chain wheel teeth 6 teeth x 9.255mm
Chain brake Yes
Clutch Yes
Automatic chain lubrication Yes
Low-kickback chain Yes
Net weight without chain and chain bar 5kg
Net weight (dry) 5.8kg
Fuel consumption (specic) 450g/kWh
L
pA
sound pressure level 101 dB(A) K=3 dB(A)
L
WA
sound power level 115 dB(A)
Vibration ahv (front handle) max. 3.04 m/s
2
K=1.5m/s
2
Vibration ahv (rear handle) max. 5.10 m/s
2
K=1.5m/s
2
Chain type Oregon: 91PJ063X
Bar type Oregon: 180SDEA041
Spark plug L8RTF
Fault Possible cause Solution
No power under load
Incorrectly gapped spark plug Clean/gap or replace plug
Runs erratically
Incorrect carburetor mixture
adjustment setting
Have carburetor adjusted by an
authorised service centre
Smokes excessively
Incorrect fuel mixture Use properly mixed fuel (40:1 ratio)
Poor performance
when operated
1. Blunt chain
2. Loose chain
1. Sharpen or replace the chain
2. Tension the chain
Engine dies
1. Empty petrol tank
2. Fuel lter in the wrong
position in the tank
1. Fill up the petrol tank
2. Completely ll the petrol tank
or re-position the fuel lter in the
petrol tank
Insufcient chain
lubrication (the cutter
rail and chain get
hot)
1. Empty oil tank for the chain
2. Oil lubrication opening
blocked
1. Top up the oil tank for the chain
2. Clean the oil lubrication hole in
the cutter bar (FIG. 5/item A)
Clean the groove in the cutter bar
Periodical service points
