B2
2
3
1
B3
3
2
1
3 Plastic clips position
B4
3. GRASS BAG FITTING (See Fig C)
Lift the safety ap (8) and insert grass bag (4).
NOTE: The motor must always be switched off
and the blade must have stopped rotating
before you assemble the assembled grass
collection bag in place.
C
1
2
4. REMOVING/EMPTYING
Lift the safety ap (8) and hold up, and
remove the grass collection bag.
WARNING! Always check the safety ap
can close the discharge outlet tightly
before using. Never lift the safety ap (8)
when the lawn mower is being used without
tted grass bag.
OPERATION
1.STARTING AND STOPPING (See Fig D1,D2)
D1
E
