Quanmax ECX-SLU0 Series User Manual

Chapter 2
28
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Table 20 CN5 Digital Input / Output Wafer
Pin Signal Name
1 +5V
2 DI0
3 DO0
4 DI1
5 DO1
6 DI2
7 DO2
8 DI3
9 DO3
1
0
GND
SMD 10P 1R 180D MALE P = 1.25mm, Tin Plated, NY46, White Insulator
[Pinrex 712-73-10TWB0]
Table 21 CN6 Serial Port 1 Wafer
Pin RS-232 RS-422
Half Duplex
RS-485
Full Duplex
RS-485
1 DCD T X
-
DATA
-
TX
-
2 DS
R
N/
A
N/
A
N/
A
3 RXD T X
+
DATA
+
TX
+
4 RT
S
N/
A
N/
A
N/
A
5 TX
D
R
X+ N/
A
R
X+
6 CT
S
N/
A
N/
A
N/
A
7 DT
R
RX
-
N/
A
RX
-
8 RI N/
A
N/
A
N/
A
9 GND GND GND GND
1
0
+5V +5V +5V +5V
SMD 10P 1R 180D MALE P = 1.25mm, Tin Plated, NY46, White Insulator
[Pinrex 712-73-10TWB0]
Table 22 CN7 Serial Port 2 Wafer
Pin RS-232 RS-422
Half Duplex
RS-485
Full Duplex
RS-485
1 DCD T X
-
DATA
-
TX
-
2 DS
R
N/
A
N/
A
N/
A
3 RXD T X
+
DATA
+
TX
+
4 RT
S
N/
A
N/
A
N/
A
5 TX
D
R
X+ N/
A
R
X+
6 CT
S
N/
A
N/
A
N/
A
7 DT
R
RX
-
N/
A
RX
-
8 RI N/
A
N/
A
N/
A
9 GND GND GND GND
1
0
+5V +5V +5V +5V
SMD 10P 1R 180D MALE P = 1.25mm, Tin Plated, NY46, White Insulator
[Pinrex 712-73-10TWB0]
