User’s Manual
Product Specifications
Dimensions 200 x 35 x 153.1 mm (WxHx D)
Weight 1.2 Kg
CPU/ Ch ips et
Inte l
®
Ivy Bridge Platform
3rd Generation Intel
®
Core™ i5/i7 Processors
Inte l
®
HM76 Express Chipset
RA M 2x DDR3 1066/1333/1600 SO- DIMM up to 16GB
Storage 1 x 2.5” SATA HDD or SSD
Front IO
3x 3.5mm Phone Jack, support 5.1 channel audio output
1x S/PDIF Output
1x eSATA
2x USB 2.0 , 4x USB 3.0
1x Pow er LED
1x Storage status LED ( HDD/CF) and 1x WiFi status LED
1x 3G external antenna
Rear IO
1x DC JACK
1x DVI- I for DVI- D or VGA output
1x HDMI
1x DP
2x RJ-45 GbE ports
1x COM Port support RS-232/422/485
2x WiFi external antenna
Expansion
Slot
2 x mini PCIe slots (Optional for 3G/WiFi/Bluetooth module)
1x SIM card slot (for 3G appliance) support user accessible
Cooling System Fan w ith Smart Fan Control
Pow er Unit
Input: 100-240 VAC
Output: +19VDC, 3.95A, 75W
Temperature /
Hu midity
Operating: 0°C to 40°C, 0%-90%, non-condensing
Storage: -20°C to 80°C, 0%-90%, non-condensing
OS Support Window s Xp/XPe/Window s 7/Window s 8/ Linux
Mou nting VESA-mount
Certifications CE, FCC Cl as s A
Table 1 QDSP-207B product specifications
