780 Handheld Test Instrument Page 35
5.2 Verifying the EDID on an HDMI HDTV or HDMI Repeater Device
This section provides procedures for verifying and viewing the EDID of an HDMI HDTV or an HDMI repeater device such
as an A/V receiver. You can also compare two EDIDs.
5.2.1 Configurations for Verifying and Viewing the EDID on an HDMI Sink Device
The following illustrations depict the typical test setups. You can either connect directly to an HDTV or to a repeater
device connected to an HDTV.
