3h: Field Wiring
3h.1: Wire Sizing
Wiring must comply with all applicable codes and ordinances. Warranty is void if wiring is not in
accordance with specifications. Copper wire is required for all power lead terminations at the unit.
The units have single point power connection. A single field supplied fused disconnect is required.
The control transformer is factory mounted.
3h.2: Electrical Data Table
67ACW-134/417
67ACW-417B
67ACW-134-C
67ACW2-134
67ACW2-134-C
67ACB-407B
Single Point Power Supply Connection
67ACP-407
67ACP-407-C
67ACB-417B
67ACP2-22 /407
Voltage Range (380-420V/50Hz/3Ph) 342-456 342-456 342-456
Minimum Circuit Amperage (MCA) 24.2+ 24.2+ 36.4+
Recommended 30 30 45
Field Fuse Size or HACR
Breaker Size
Maximum 42 42 63
Compressor 15.5 15.5 15.5
Rated Load Amps (RLA)
Fan 1.8 6.8 1.8
Compressor 111 111 111
Locked Rotor Amps (LRA)
Fan 6.5 24 6.5
NOTES:
1.
Voltage within 10% of nameplate rating.
2.
Phase imbalance within 3%.
3.
Single conductors should be used for power connections.
4.
Single point disconnect of electrical supply to the unit is required. This supply must be fused.
5.
Field Fuse Size for recommended and maximum is based on the use of a time-delay fuse.
6.
Compressor RLA values are for wire sizing purposes only and do not reflect normal operating
current draw at rated capacity.
7.
All terminal block connections must be made with copper (type THW) wire.
8.
All field wire size values given in the table apply to 75°C rated wire.
9.
Ampere correction factors must be applied for ambient temperatures in sizing the power lead
wire. Refer to the local electrical code handbook.
10.
For Heat Pumps fitted with optional Boosters, please refer to the equipment nameplate for
maximum current draw, the circuit breaker, or similar device supplying the unit should be one
current range above that of the equipment nameplate.
Document Number : QDC0049PD-5 Page 16 of 33
