Technical Data
quantum
MASCHINEN - GERMANY
© 2007
GB
Page 14 Drilling machine B 13 / B14 / B16 / B20 / B25 / B32 Version 1.2.5 18 / 01 / 2008
2 Technical Data
The following data which give dimensions and weight are the manufacturer’s authorized
machine data.
2.1 Power connection
B 13 B 14 B 16 B 20
B 20 Vario
B 25
B 25 Vario
B 32
B 32 Vario
power connection~50Hz
230 V
300 W
230 V
350W
230 V
450 W
3 x 400 V
550 W
3 x 400 V
550 W
3 x 400 V
1,1 kW
or
230 V
550 W
230V
550 W
230V
1,1 kW
2.2 Drilling capacity
B 13 B 14 B 16 B 20 B 25 B 32
drilling capacity in steel
[mm]
13 14 16 20 20 32
reach [mm] 104 104 125 170 170 225
spindle sleve travel [mm] 50 50 65 80 80 125
2.3 Spindle holding fixture
B 13 B 14 B 16 B 20 B 25 B 32
spindle holding fixture firm/B16 firm/B16 MK2 MK2 MK3 MK4
2.4 Drilling machine table
B 13 B 14 B 16 B 20 B 25 B 32
slewable on the spindle
axis [mm]
length x width of the work-
ing area
160 x 160 160 x 160 200 x 200 275 x 275 275 x 275 360 x 360
T-groove dimension [mm] 14 14 14 14 14 14
maximum distance [mm]
spindle table
240 340 390 450 760 660
working area stand [mm]
length x width of the work-
ing area
135 x 175 140 x 180 160 x 170 205 x 200 235 x 220 260 x 270
