Quantum Blast User Manual

7 Quantum BlastBLAST/REV D/OCTOBER 2002
SEATBACK
ARMRESTS
REMOTE PLUS
KEYPAD
(SWING-AWAY
FOOTRESTS)
DRIVE WHEEL
CASTER
WHEELS
POWER
BASE
ASSEMBLY
YOUR QUANTUM BLAST
Your Quantum Blast has two main assemblies: the seat and the power base. See figures 2 and 3. There are a wide range of
seating options for the Blast, as well as custom configurations. Commonly, the seating assembly contains a seatback, arm-
rests, joystick, and footrest mounts. Your Blast may feature a tilt or recline seating system, alternate joystick mount, or a
number of other specialty features to further enhance your mobility. For information on your seating system, refer to the
ownerís manual that accompanies the seating system.
The power base assembly of the Blast consists of two casters wheels, two drive wheels (see figure 2 and 3), two anti-tip
wheels (see figure 3), two drive motors (see figures 7 and 8), two batteries, an electronics controller, and a battery charger
(see figure 4). The Remote Plus controller is standard equipment on the Quantum Blast.
Fig 2. Blast Front View
SEAT
ASSEMBLY
MOTOR/BRAKE ASSEMBLY
JOYSTICK
YOUR QUANTUM BLAST
FOOTREST
MOUNTS

Quantum Blast Specifications

General

Brand	Quantum
Model	Blast
Category	Wheelchair
Language	English
