Chapter 5: Media
Bar Code Labels
72 Quantum LTO-9 HH SAS User’s Guide
Note: The tape drive does not require bar code labels, but you may
choose to use labels for tape cartridge identification purposes.
When attaching a bar code label to a tape cartridge, place the label only
in the recessed label area (see 5 in Figure 8
on page 66). A label that
extends outside of the recessed area can cause loading problems in the
drive.
Caution: Do not place any type of mark on the white space at either
end of the bar code.
Figure 10 Sample bar code
label on the LTO Ultrium 8 Tape
Cartridge
Guidelines for Using Bar Code Labels
Apply the following guidelines whenever using bar code labels:
• Use only Quantum-approved bar code labels.
• Do not reuse a label or reapply a used label over an existing label.
• Before you apply a new label, remove the old label by slowly pulling
it at a right angle to the cartridge case.
• Use peel-clean labels that do not leave a residue after being
removed. If there is glue residue on the cartridge, remove it by
gently rubbing it with your finger. Do not use a sharp object, water,
or a chemical to clean the label area.
• Examine the label before applying it to the cartridge. Do not use the
label if it has voids or smears in the printed characters or bar code.
