Quantum Q6 Series - Page 10


Figure 1. Q6 Series Electrical Components
Identification Key
1. To Motor Connector
2. Controller Power Module
3. Controller Connector
4. To Battery Connectors
5. Main Circuit Breaker
6. Quick Release Battery Connectors
7. Fender Lights
1
4
2
1
7
7
3
5
6
