IMPphoneusermanual

Interface



 Item Whatyoucandowithit

（left）

poweradapterjack

input：220VAC

output：12VDC

（middle）

PCEthernetport

RJ45，accesstoPC

（right）

LANEthernetport

RJ45，accesstoLAN

（top）

PSTNjack RJ11,connectingPSTNline

（middle）

Handsetjack RJ9,connectinghandset

（bottom）

Headsetjack RJ9,connectingheadset

Note:

1Connecthandsetcordtophone'sjack.Putthelong,directline side into the

phonehandsetjack.

2Installthefootstandintothephonebase.

3Connectthepoweradaptertothephoneandintoanelectricsocket.
