TECHNOX-System-Exclusive Format (Version 1.0)
Identity Request
Byte No. Value Remarks
0 F0 System Exclusive start command
1 7E Common Non-Real-Time message
2 cc channel number = TECHNOX system channel *
3 06 general information
4 01 identity request
5 F7 end of System Exclusive
Identity Reply
Byte No. Value Remarks
0 F0 System Exclusive start command
1 7E Common Non-Real-Time message
2 cc channel number = TECHNOX system channel *
3 06 general information
4 02 identity reply
5 3F QUASIMIDI ID
6 22 TECHNOX id
... ... ...
10..13 vv vv vv vv Version no. (4 ascii characters, i.e ‘2.00’)
10 F7 end of System Exclusive
* note that if cc = 7Fh the TECHNOX respond regardless of what
master channel it is on
Request Data from device:
Byte No. Value Remarks
0 F0 System Exclusive start command
1 3F Quasimidi id number
2 dv device number = TECHNOX System channel
3 22 TECHNOX id number
4 52 (R)equest data
5 ah adress high
6 am adress mid
7 al adress low
8 dh data count high
9 dl data count low
10 F7 end of System Exclusive
Dump Data to device:
Byte No. Value Remarks
0 F0 System Exclusive start command
1 3F Quasimidi id number
2 dv device number = TECHNOX System channel
3 22 TECHNOX id number
4 44 (D)ump data
5 ah adress high
6 am adress mid
7 al adress low
8... dt data (7 bit)
... F7 end of System Exclusive
18.) MIDI-Sysex-Data format
