BOW THRUSTER BTQ250 - BTQ300 IT GB - REV002A
WARNING: make sure that the power supply to the
electric motor is not switched on when maintenance
operations are carried out.
Quick
®
Bow Thrusters are made in materials that are resist-
ant to the sea environment: In any case, it is indispensable
to periodically remove salt deposits that form on the outer
surfaces to avoid corrosions and consequent system inef-
ficiency
Dismantle once a year, following the points below:
• Keep the propeller (13 and 14) and the gearleg (12) clean.
• Paint the propeller and the gearleg with anti-vegetative
paint before each season.
WARNING
: do not paint the zinc anode (16), the seal-
ings and the propeller shafts. Be careful not to allow
paint to penetrate in the “tracks” of the gearleg (12)
in which the propeller hub moves.
• Check the zinc anode (16) frequently.
• Replace the zinc anode before every season or when it is
more than half consumed.
• After any maintenance, make sure that the bolts (19) that
lock the flange (8) to the gearleg (12) are well tightened.
• After every maintenance, make sure that the propeller (13
and 14) is well tightened and that the bolts (1) locking the
electric motor (3) are tight.
• Make sure that all electrical connections are clean and
firmly fixed ( 29 and 30).
• Make sure that the batteries are in good condition.
POS.
DESCRIPTION CODE
1 Motor mounting screw
MBV1230MXCE0
2 Motor mounting washer
MBR12X000000
3A Motor 10KW
EMFEL1K24000
3B Motor 12KW
EMFEL2K24000
4 Key 6x6x25
MBH0606025X0
5 Half-joint
MMSGM1900000
6 Even tension device
PVPR70000000
7 Half-joint
MMSGM2400000
8 Motor flange
SLMMEM300000
9 O-Ring
PGR041750000
10 Gearbox gasket
PGRDEL300000
11 Key 6x6x20
MBH0606020X0
12 Gearleg
MREM30000000
13 Starboard propeller
PVEL30R00000
14 Port propeller
PVEL30L00000
15 Self-braking nut M18
MBD18MXET000
16 Anode tip
MMANBTQ30000
17 Anode tip mounting screw
MBV0635MBCE0
18 Washer Ø14
MBR14X000000
19 Gearleg mounting screw M14
MBV1475MXCE0
20 Clamp reversing contactor unit
MMSTBTQ35000
21 Screw M5x06
MBV0506MTCT0
22 Grower Ø5
MBG05X000000
23 Washer Ø5
MBR051510X00
24 Screw M5x10
MBV0510MXCE0
25 Reversing contactor unit
350A 24V
ERBTQ2435000
26 Carter spacer B
MBTCB2600TMM
27 Fasteners carter
reversing contactor unit
PCCCBTQB0000
28 Fasteners carter
reversing contactor unit
PBD04STPN000
29 Negative reversing contactor
SAECCCBTQNG0
30 Command wire
SAECCCBTQCM0
MAINTENANCE
