Quick BTQ2512012 - Page 28

28
BOW THRUSTER BTQ250 - BTQ300 IT GB - REV002A
BTQ2512012 = 390 (15
11
/32) • BTQ2512024 = 400 (15
3
/4)
BTQ2514024 = 400 (15
3
/4) • BTQ2524024 = 410 (16
5
/32)
Ø 266 (10
15
/32)
Ø 250 (9
27
/32)
BTQ3025024 = 420 (16
17
/32) • BTQ3027024 = 480 (18
7
/8)Ø 322 (12
11
/16)
Ø 300 (11
11
/16)
BTQ25
BTQ30
BOW THRUSTERS
DIMENSIONI / DIMENSIONS mm (inch)
