Quick BTQ2524024 - BASIC SYSTEM DIAGRAM

29
BOW THRUSTER BTQ250 - BTQ300 IT GB - REV002A
BOW THRUSTERS
SISTEMA BASE / BASIC SYSTEM
M1
AA
SS
SX
+
-
DX
-
M2
MOTOR
BATTERY
12/24V
BATTERY
ISOLATOR
BLACK
FUSE
4A FAST
FUSE
see table on
page 4/18
SWITCH
RED
BLACK
RED
TCD 1042 TCD 1022
*
*
* Negativo dei gruppi batteria in comune.
* Common negative for the battery groups.
TO THE
SERVICES
BATTERY
SPLITTER
(OPTIONAL)
CONTROL
CABLE
EXTENSIONS
(OPTIONALS)
BTQ25 - BTQ30
