MANUALE D’INST
ALLAZIONE E USO
BTR185
- REV009A
23
IT
BTR185
Dimensioni elica di manovra retrattile
A
60 (2
23
/
64
)
120 (4
23
/
32
)
B
317 (12
31
/
64
)
150 (5
29
/
32
)
370 (14
9
/
16
)
599 (23
37
/
16
)
MOD
.
BTR1806512
BTR1806524
BTR1808512
BTR1808524
BTR1810512
BTR1810524
A
- mm (inch)
713 (28”
1/16)
743 (29”
1/4)
801 (31”
17/32)
B
- mm (inch)
292 (11” 1/2)
323 (12”
23/32)
384 (15”
1/8)
22
24
