20
CHARACTERISTICS AND INSTALLATION
GB
RETRACTABLE THRUSTER BTR185 - IT GB - REV004B
MODELS BTR1806512 BTR1806524 BTR1808512 BTR1808524 BTR1810512 BTR1810524
N° Propellers 2 contra-rotating
Tunnel Ø 185 mm (7” 18/64)
Motor Power 3,0 KW 4,0 KW 6,0 KW
Voltage 12 V 24 V 12 V 24 V 12 V 24 V
Section of wire
2 x 50mm
2
(2 x AWG 1)
50mm
2
(AWG 1)
2 x 70mm
2
(2 x AWG 2/0)
2 x 50mm
2
(2 x AWG 1)
2 x 95mm
2
(2 x AWG 3/0)
2 x 50mm
2
(2 x AWG 1)
Fuse 355A 200A 500A 355A 2 x 325 A 400A
Thrust
65 kgf (143,3 lb) 85 kgf (187,4 lb) 105 kgf (231,5 lb)
Weight 38,5 kg (84,9 lb) 42,5 kg (93,7 lb) 47,5 kg (104,7 lb)
INSTALLATION REQUISITES
As said, despite all components and moving mechanical parts are of high quality, the correct installation of the retractable
propulsion unit is fundamental for a safe and efficient use of the boat, as well as of the same propulsion unit.
Please note that the installation of such unit is an operation requiring experience as well as technical competence. It is
recommended to entrust the installation to competent staff and to consult the manufacturer or naval architects to fully
evaluate the entity of the work.
The Quick retractable thruster
®
has two individual movements.
The main movement, relating to the propulsion part, is of tilting type. The hinges on which the movement happens are
conceived to confer high resistance to the set and are located on the flat flange surface that joins the pre-assembled
structure to the hull solid support.
The secondary movement relates to the closing of the through-hull fitting from where the tunnel exits. This movement is
of parallel link type and its range is not a simple revolution around the main pivot but a movement act at expelling, without
interferences, the closing plate from the hole made in the hull.
Electric motor, gear, levers and all other components are supplied by Quick
®
, already assembled on the supporting struc-
ture in GRP and do not require adjustments, adaptations or sealing, unless indicated in this manual.
The Quick retractable thruster
®
is sold separately from the counter flange, that can be supplied in different materials to
comply with the different types of hulls. Quick
®
is able to supply stainless steel, aluminium alloy or GRP supports, funda-
mental for quick, solid and precise installation.
For the fi breglass hulls the support must be laminate in the hull respecting the current Standards relating to joints.
The propulsion unit distributes mechanical stresses to the hull through the counter flange. The force of the joint will be
determined by overlapped, up to standard, laminates.
For aluminium alloy hulls, like for stainless steel hulls, the support must be welded to the hull.
If correct, the installation of a boxed structure like that of the support, can give greater sturdiness to the hull. Consult the
manufacturer, naval architects and/or specialised companies to evaluate additional work which beams and ribs near the
retractable propulsion unit.
BEFORE USING THE RETRACTABLE THRUSTER, CAREFULLY READ THIS USER MANUAL.
IF IN DOUBT, CONTACT YOUR NEAREST QUICK
®
DEALER.
WARNING:
the thruster Quick
®
have been designed and manufactured for nautical use.
Do not use these appliances for other uses.
Quick
®
shall accept no responsibility for direct or indirect damages caused by improper use of the appliance or
an improper installation.
The thruster is not designed for maintaining loads generated in particular atmospheric conditions (storms).
It is recommended to entrust arrangement and positioning of the tube on the hull to a professional. These are
general instructions and do not, in any way, illustrate details of the tunnel arrangement operations, which compe-
tence is of the boatyard. The installer will be fully responsible for any damages caused by a faulty installation of
the tunnel.
Do not install the electric motor near easily inflammable objects.
THE PACKAGE CONTAINS:
retractable thruster - user's manual - conditions of warranty.
QUICK
®
”ACCESSORIES RECOMMENDED:
TCD 1022 - TCD 1042 - TCD1044 - TCD1062 - TMS - TSC
Quick
®
reserves the right to introduce changes to the equipment and the contents of this manual without prior notice.
In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text.
