Quick GENIUS Series User Manual

25
GB
GP2 SERIES GENIUS 500/1200 - REV001A
MAINTENANCE
30
22
29
19
A
26
27
26
20
19
40
41
42
31
38
32
33
26
43
16
15
14
13
18
6
11
32
33
34
35
36
37
35
39
17
22
10
22
22
25
26
26
28
7
3
4
1
5
B
C
L
I
M
N
H
F
G
E
D
GP2 1200 FF
Number references given on pages 22-23.
POS. DESCRIPTION
A Shaft
B Windlass pin guide
C Screw
D Pin
E Spring pin
F Gypsy cover
G knob
H Gypsy cover screw
I screw
L Pin
M Spring pin
N Pilot boss
