Quick GP2 1200 - Wiring Diagram; GPSeries Connection Example

GP Series
EN
-
+
M1 M2
MULTI-PURPOSE
PUSH-BUTTON
PANEL
WINDLASS
BATTERY
HYDRAULIC-
MAGNETIC
CIRCUIT
BREAKER
(SEE TABLE ON
PAGE 5)
REVERSING
CONTACTOR BOX
MOD. T6411-12 (12V)
MOD. T6415-12 (12V)
MOD. T6415-24 (24V)
FOOT-OPERATED SWITCHES
BROWN
BROWN
BLACK
BLACK
BLUE
BLUE
A1
A2
C
4A FUSE
(12V)
2A (24V)
L = L1 + L2 + L3 + L4 + L5
L3
L2
L1
L4
L5
CHAIN-COUNTER
PUSH-BUTTON PANEL
RRC REMOTE RADIO CONTROLS
POCKET
SIZE
RECEIVER PUSH-BUTTON
PANEL
TRANSMITTERS
CHAIN COUNTER
FROM PANEL
CONTROLS FROM
CONTROL BOARD
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
9
5.0 - Example of connection of GPSeries
with recommended Quick
®
accessories for the operation of the windlass
5 - Wiring diagram
