HRC - REV004A
MULTIPURPOSE CONTROL PANEL
The Quick
®
multipurpose control panel is an instrument designed for the remote control of various moving
systems on board a boat, including mini-crane, gangplank, swimming ladder, anchor hoist.
INSTALLATION
BEFORE USING THE INSTRUMENT PLEASE STUDY THIS USER MANUAL. IN CASE OF ANY
DOUBT PLEASE CONTACT THE RETAILER OR QUICK
®
CUSTOMER SERVICE.
In case of discordance or errors in translation between the translated version and the original text in
the Italian language, reference will be made to the Italian or English text.
This device was designed and constructed for use on recreational crafts.
Other forms of use are not permitted without written authorization from the company Quick
®
.
The control was designed for the purposes described in this user manual. The company Quick
®
does
not accept any responsibility for direct or indirect damage caused by the improper use of the device, by
incorrect installation, or for any errors in this user manual.
WARNING: the electrical appliance controlled by the control panel must be provided with safety
systems to prevent damage to persons, things, or the environment that might result from the
defective operation of the control panel.
THE OPENING OF THE INSTRUMENT BY UNAUTHORIZED PERSONNEL MAKES THE
WARRANTY VOID.
THE PACKAGE CONTAINS:
control panel - support - socket - socket seal and cover - screws - drilling
template - personalised adhesives (only in certain models) - the present manual of use.
FITTING THE SOCKET
A typical installation procedure is described below.
It is not possible to define a single procedure that is applicable in every situation.
Adapt the procedure described here to your own requirements.
Identify the most appropriate position for the socket seating on the basis of the following criteria:
• The socket must be positioned so that it can easily be reached by the operator.
• Choose a clean, smooth, flat location.
• Rear access is required for installation and maintenance.
• There must be sufficient space behind the chosen position for the passage of the socket cable.
• The back of the socket must not be exposed to contact with water or humidity.
• Take particular attention when drilling the panels or parts of the boat. The holes must not weaken or
cause the breakage of structural elements of the boat.
CHARACTERISTICS AND INSTALLATION
F
F
