QuickJack™ Portable Car Jack 3 P/N 5900263 — Rev. B6 —September 2023
Table of Contents
Introduction 3 Operation 36
Shipping 5 Maintenance 48
Safety 5 Troubleshooting 51
Components 8 Wiring Diagrams 55
Accessories 10 Labels 56
Specifications 11 Parts Sheets 59
FAQ 13 Declaration of Conformity 67
Setup Checklist 14 Maintenance Log 69
Setup 15 ALI Store 71
Introduction
This manual covers all models of the QuickJack portable car jack, which makes Vehicle maintenance
in your garage or at the track fast and easy. QuickJack models include:
• 3500SLX: Raises Vehicles up to 3,500 lbs. / 1,588 kg on a short frame.
• 5000TL: Raises Vehicles up to 5,000 lbs. / 2,267 kg on a standard frame.
• 7000TL: Raises Vehicles up to 7,000 lbs. / 3,175 kg on a standard frame.
• 5000TLX: Raises Vehicles up to 5,000 lbs. / 2,267 kg on an extended frame.
• 7000TLX: Raises Vehicles up to 7,000 lbs. / 3,175 kg on an extended frame.
• 6000ELX: Raises Vehicles up to 6,000 lbs. / 2,721 kg on a super long frame.
This manual is mandatory reading for all QuickJack users, including anyone who sets it up,
operates it, maintains it, or repairs it. You can always find the latest version of the Manual
on the QuickJack Website. Scan this QR Code for up-to-date information and videos
on the QuickJack.
⚠ DANGER Be careful when setting up, operating, maintaining, or repairing your unit; failure to
do so could result in property damage, product damage, injury, or (in very rare
cases) death. Make sure only authorized personnel operate the unit. An authorized
technician must perform all repairs. Do not make modifications to the unit; this
voids the warranty and increases the chances of injury or property damage. Make
sure to read and follow the instructions on the labels on the unit.
Keep this manual on or near your QuickJack so that anyone who uses or services it can read it.
For technical support, visit quickjack.com/support or email QuickJack Technical Support at
support@quickjack.com. You can also request parts (be sure to have the serial and model
numbers of your unit available).
