QuickJack 7000TL - Sheet2; Drawing View2; Drawing View3; Drawing View4

21.078in
535.4mm
42.395in
1076.8mm
FULL RISE
20.569in
522.4mm
40.987in
1041.1mm
TOP LOCK
14.782in
375.5mm
31.493in
799.9mm
LOWEST LOCK
3.543in
90.0mm
24.144in
613.3mm
FULLY LOWERED
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5215921
7000TL FRAME
ASSEMBLY, R.H.
1:15
SCALE:
