IMPROPER SET-UP
MUST BE
PARALLEL
WITHIN 2”
MUST BE
PARALLEL
WITHIN 2”
PROPER SET-UP
ALWAYS MAKE SURE QUICKJACK FRAMES ARE PARALLEL WITHIN 2” AND ALIGNED EVENLY FRONT AND
BACK AS SHOWN IN THE DIAGRAM. FAILURE TO DO SO COULD CAUSE QUICKJACK FRAMES TO BECOME
UNSTABLE AND NOT REST SQUARELY ON FLOOR SURFACE.
LONGITUDINAL LATITUDINAL
MUST BE PARALLEL
WITHIN 2”
MUST BE PARALLEL
WITHIN 2”
MUST BE PARALLEL
WITHIN 2”
MUST BE PARALLEL
WITHIN 2”
